Description
JVC GY-HM250SP UHD 4K Streaming Camcorder with HD Sports Overlays
The JVC GY-HM250SP UHD 4K Streaming Camcorder with HD Sports Overlays is a full-featured pro camcorder that enables a single operator to add lower-thirds and titles while recording in HD or streaming—no external character generator or switcher is required. It features a 1/2.3″ sensor and captures UHD 4K video at 24/30p, and 4:2:2 4K at 24/30p. This versatile camera offers you the option of recording UHD 4K at rates up to 150 Mb/s to SDXC Class 3 cards or up to 70 Mb/s to SDXC/SDHC Class 10 cards. In HD mode, the GY-HM250SP can display score overlays for sports such as football, baseball, basketball, hockey, soccer, and volleyball. Score overlays may be placed in various screen positions, and a camera operator can update the score via Wi-Fi using a smartphone or tablet. The GY-HM250SP is also compatible via Wi-Fi with a scoreboard-integrated Sportzcast Scorebot.
The GY-HM250SP’s integrated IP engine enables you to stream Full HD in the field directly from the camcorder and offers remote camera control and monitoring from your mobile device or laptop. Compatible with RTMP, Zixi, and Wowza streaming, the GY-HM250SP offers one-click zeroconf configuration when using a common LAN between cameras. A firmware update brings Facebook Live integration to the camera, streamlining the connection process. In HD mode, custom graphics can be created and controlled via a browser-controlled tablet or smartphone. The GY-HM250SP also comes with pre-installed color schemes and the ability to upload icons or logos to add a personalized look to your footage.
An integrated 12x zoom lens with a tele-macro function provides a 35mm equivalent focal range of 29.6 to 355mm, and a 24x dynamic zoom mode is available when recording in HD. For composing and monitoring video, the camcorder features a 3.5″ LCD, a 0.24″ viewfinder, and a smart focus assist function. Additional features include dual SDHC/SDXC card slots, two internal ND filters, and a built-in stereo microphone. Designed to fit into professional workflows, the JVC GY-HM250SP camcorder comes with 3G-SDI and HDMI outputs and dual XLR audio inputs. A top handle unit with the integrated audio box, a 7.4 VDC battery, and an AC adapter are included with the camera.
Note:
Sports Score Overlays in HD Mode
Note:
- 12x optical zoom with 24x dynamic zoom in Full HD
- 3.5″ LCD display, and 2.4″ color EVF
- Dual SDXC/SDHC card slots
- Two internal ND filter settings
- 2-channel XLR audio inputs with phantom power
- Integrated stereo microphone
- A histogram display aids in calculating your exposure
- Tally with steady and blinking settings
| Brands | JVC |
|---|
JVC GY-HM250 Specs
| Sensor Resolution | Effective: 12.4 Megapixel |
| Sensor Type | 1/2.33″-Type CMOS Sensor |
| Image Stabilization | Optical in Integrated Lens |
| Built-In ND Filter | Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16) ND Filters |
| Capture Type | Video Only |
| Shutter Type | Electronic Rolling Shutter |
| Shutter Speed | 1/10000 to 1/6 Second |
| Gain | 0 to 24 dB (Native) 30 to 36 dB (Expanded) |
| White Balance | 2300 to 15,000K |
| Focal Length | 4.6 to 56mm (35mm Equivalent Focal Length: 29.6 to 355mm) |
| Optical Zoom Ratio | 12x |
| Max Digital Zoom | 24x |
| Maximum Aperture | f/1.2 to 3.5 |
| Filter Size | 62 mm |
| Control Rings | Focus Zoom |
| Focus Control | Autofocus Manual Focus |
| Internal Recording Modes | H.264 3840 x 2160 at 23.98/25/29.97 fps [70 to 150 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/100/ fps [35 to 50 Mb/s] 1920 x 1080i at 50/59.94 fps [24 to 50 Mb/s] 1920 x 1080p at 50/59.94 fps [12 to 28 Mb/s] 1440 x 1080i at 50/59.94 fps [5 to 9 Mb/s] 1280 x 720 at 59.94 fps [8 Mb/s] 960 x 540 at 23.98/25/29.97 fps [3 Mb/s] 720 x 480i at 50/59.94 fps [8 Mb/s] 720 x 576i at 50 fps [8 Mb/s] 480 x 270 at 23.98/25/29.97 fps |
| Fast-/Slow-Motion Support | No |
| Built-In Microphone Type | Stereo |
| Audio Recording | AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio AVCHD: 2-Channel 16-Bit 48 kHz AC-3 Audio |
| IP Streaming | H.264, H.265, MPEG2, RTMP, RTP, RTSP, ZIXI 1920 x 1080 at 50i, 59.94i (3.0 to 12.00 Mb/s) 1280 x 720 at 25p, 29.97p, 50p, 59.94p (1.5 to 12.00 Mb/s) 720 x 576 at 50i (0.3 to 8.0 Mb/s) 720 x 480 at 59.94i (0.3 to 8.0 Mb/s) 640 x 360 at 25p, 29.97p, 50p, 59.94p |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC (UHS-I) [U3/V30 or Faster Recommended] |
| Video I/O | 1 x BNC (3G-SDI) Output 1 x HDMI Output 1 x 1/8″ / 3.5 mm TRRS A/V Output |
| Audio I/O | 2 x XLR 3-Pin (+48 V Phantom Power) Input 1 x 1/8″ / 3.5 mm TRS Stereo Microphone (Plug-in Power) Input 1 x 1/8″ / 3.5 mm TRRS Headphone/Mic Headphone Output |
| Power I/O | 1 x Barrel (12 VDC) Input |
| Other I/O | 1 x USB-A (USB 2.0) Data Output 1 x Mini-USB (USB 2.0) Output 1 x 2.5 mm Sub-Mini Control Input |
| Size | 3.5″ |
| Resolution | 920,000 Dot |
| Display Type | Articulating LCD |
| Type | Built-In Electronic (LCOS) |
| Size | 0.24″ |
| Resolution | 1,560,000 Dot |
| Focus Type | Auto and Manual Focus |
| Focus Mode | Automatic, Manual Focus |
| Operating Temperature | 32 to 72°F / 0 to 40°C |
| Storage Temperature | -4 to 122°F / -20 to 50°C |
| Operating Humidity | 30 to 80% |
| Battery Type | JVC SSL-JVC50 |
| Power Consumption | ≥7.9 W |
| Tripod Mounting Thread | 1/4″-20 Female |
| Accessory Mount | 1 x 1/4″-20 Female 1 x Cold Shoe Mount |
| Dimensions (W x H x D) | 12.1 x 7.5 x 5.9″ / 307 x 191 x 149 mm (With Handle) |
| Weight | 3.53 lb / 1.6 kg |
| Package Weight | 6.075 lb |
| Box Dimensions (LxWxH) | 13.6 x 11 x 10″ |
